6-92
6
îš‹ Inverter Error Codes
The content of a current fault and faults that have occurred earlier can be read out by Memobus using the Fault
Trace (U2-) and the Fault History (U3-) parameters. The fault codes are shown in the table below.
îš‹ ENTER Command
When parameters are written in the Inverter from a PC/PLC using MEMOBUS communications, the parame-
ters are temporarily stored in the parameter data area of the Inverter. To enable these parameters in the param-
eter data area, an ENTER command must be used.
There are two types of ENTER commands:
• ENTER commands that enable parameter data in RAM only (changes will be lost after power loss)
• ENTER commands that write data into the EEPROM (non-volatile memory) of the Inverter and enable the
data in RAM at the same time.
An ENTER command is performed by writing 0 to register number 0900H or 0910H.
Fault
Code
Fault Description
Fault
Code
Fault Description
Fault
Code
Fault Description
01H PUF 14H EF6 37H SE1
02H UV1 15H EF7 38H SE2
03H UV2 18H OS 39H SE3
04H UV3 19H DEV 83H CPF02
06H GF 1AH PGO 84H CPF03
07H OC 1BH PF 85H CPF04
08H OV 1CH LF 86H CPF05
09H OH 1DH OH3 87H CPF06
0AH OH1 1EH OPR 88H CPF07
0BH OL1 1FH ERR 89H CPF08
0CH OL2 21H CE 8AH CPF09
0DH OL3 22H BUS 8BH CPF10
0EH OL4 25H CF 91H CPF20
0FH RR 26H SVE 92H CPF21
10H RH 27H EF0 93H CPF22
11H EF3 28H FBL 94H CPF23
12H EF4 29H UL3
13H EF5 2AH UL4
Register Address. Contents
0900H Write parameter data to EEPROM, RAM is refreshed
0910H Parameter data are not written to EEPROM, but refreshed in RAM only.
IMPORTANT
• The EEPROM can be written up to 100,000 times only. Do not frequently execute ENTER commands (0900H)
which write into the EEPROM.
• The ENTER command registers are write-only registers. Consequently, if these registers are read out, error code
02H is returned.
• An ENTER command is not required if reference or broadcast data are sent to the inverter.
