Omron VARISPEED L7 User Manual

6-10
6
 Emergency Stop
If a digital input terminal (H1-) is set to 15 or 17 (emergency stop), this input can be used to fast stop the
inverter in the case of emergency. In this case the emergency stop deceleration time set in C1-09 is used. If the
emergency stop is input with an NO contact, set the multi-function input terminal (H1-) to 15, if the emer-
gency stop is input with an NC contact, set the multi-function input terminal (H1-) to 17.
After the emergency stop command has been input, the operation cannot be restarted until the Inverter has
stopped. To cancel the emergency stop, turn OFF the run command and emergency stop command.
Related parameters
Multi-function Digital Inputs (H1-01 to H1-05)
Parameter
No.
Name
Factory
Setting
Change
during
Operation
Control Methods
V/f
Open
Loop
Vector
Closed
Loop
Vector
Closed
Loop
Vector
(PM)
C1-09 Emergency stop time 1.50 s No A A A A
Set
Value
Function
Control Methods
V/f
Open
Loop
Vector
Closed
Loop
Vector
Closed
Loop
Vector
(PM)
15 Emergency Stop, NO contact Yes Yes Yes Yes
17 Emergency Stop, NC contact Yes Yes Yes Yes
