Varispeed L7 Models
The Varispeed L7 Series includes Inverters in two voltage classes: 200 V and 400 V. The maximum motor capacities
vary from 3.7 to 55 kW (23 models).
Table 1.1 Varispeed L7 Models
Voltage
Class
Maximum
Motor
Capacity
kW
Varispeed L7
Specifications
(Always specify through the protective structure when ordering.)
Output
Capacity
kVA
Basic Model
Number
IEC IP00
CIMR-L7Z
NEMA 1
CIMR-L7Z
IEC IP20
CIMR-L7Z
200 V class
3.7 7 CIMR-L7Z23P7 23P71 23P77
5.5 10 CIMR-L7Z25P5 25P51 25P57
7.5 14 CIMR-L7Z27P5 27P51 27P57
11 20 CIMR-L7Z2011 20111 20117
15 27 CIMR-L7Z2015
20151
20157
18.5 33 CIMR-L7Z2018 20181 20187
22 40 CIMR-L7Z2022 20220 20221 20227
30 54 CIMR-L7Z2030 20300 20301 20307
37 67 CIMR-L7Z2037 20370 20371 20377
45 76 CIMR-L7Z2045 20450 20451 20457
55 93 CIMR-L7Z2055 20550 20551 20557
400 V class
3.7 7 CIMR-L7Z43P7 43P71 43P77
4.0 9 CIMR-L7Z44P0 44P01 43P77
5.5 12 CIMR-L7Z45P5 45P51 45P57
7.5 15 CIMR-L7Z47P5 47P51 47P57
11 22 CIMR-L7Z4011 40111 40117
15 28 CIMR-L7Z4015 40151 40157
18.5 34 CIMR-L7Z4018 40181 40187
22 40 CIMR-L7Z4022 40220 40221 40227
30 54 CIMR-L7Z4030 40300 40301 40307
37 67 CIMR-L7Z4037 40370
40371 40377
45 80 CIMR-L7Z4045 40450 40451 40457
55 106 CIMR-L7Z4055 40550 40551 40557
