Note: Communications error details are stored until an error reset is input.
002CH
Inverter status
Bit 0 Operation 1: Operating
Bit 1 Zero speed 1: Zero speed
Bit 2 Frequency agree 1: Agreement
Bit 3 User-defined speed agree 1: Agreement
Bit 4 Frequency detection 1: 1: Output frequency ≤ L4-01
Bit 5 Frequency detection 2: 1: Output frequency ≥ L4-01
Bit 6 Inverter startup completed 1: Startup completed
Bit 7 Undervoltage detection 1: Detected
Bit 8 Baseblock 1: Inverter output baseblock
Bit 9 Frequency reference mode 1: Not communication 0: Communication option
Bit A Run command mode 1: Not communication 0: Communication option
Bit B Overtorque detection 1: Detected
Bit C Frequency reference lost 1: Lost
Bit D Restart enabled 1: Restarting
Bit E Error (including MEMOBUS communications time-out) 1:Error occurred
Bit F MEMOBUS communications time-out1: Timed out
002DH
Multi-function contact output status
Bit 0 Multi-function contact output 1 (terminal M1-M2) 1: ON 0: OFF
Bit 1 Multi-function contact output 2 (terminal M3-M4) 1: ON 0: OFF
Bit 2 Multi-function contact output 3 (terminal M5-M6) 1: ON 0: OFF
Bits 3 to F Not used
002EH - 0030H Not used
0031H Main circuit DC voltage
0032H Torque Monitor U1-09
0033H Power Monitor U1-08
0034H - 003AH Not used
003BH CPU software number
003CH Flash software number
003DH
Communications error details
Bit 0 CRC error
Bit 1 Invalid data length
Bit 2 Not used
Bit 3 Parity error
Bit 4 Overrun error
Bit 5 Framing error
Bit 6 Time-out
Bits 7 to F Not used
003EH kVA setting
003FH Control method
Register Address. Contents
