Omron VARISPEED L7 User Manual

5-54
5
T2: Autotuning 2
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
Open
Loop
Vector
Closed
Loop
Vector
Closed
Loop
Vector
(PM)
Display
T2-01
Motor output
power
Sets the output power of the
motor in kilowatts.
0.00 to
75.00
3.70
kW
*1
*1. The factory setting depends on the Inverter capacity. (The value for a 200 V Class Inverter for 3.7 kW is given.)
No - - - Yes 730H 4-4
Mtr Rated Power
T2-02
Motor base fre-
quency
Sets the motor base frequency.
20 to
3600
150
rpm
No - - - Yes 731H 4-4
Base Frequency
T2-03
Motor rated volt-
age
Sets the rated voltage of the
motor.
0 to
480.0
200.0 V
*2
No - - - Yes 732H 4-4
Rated Voltage
T2-04
Motor rated cur-
rent
Sets the rated current of the
motor.
0.00 to
200.00
14.60 A
*1
No - - - Yes 733H 4-4
Rated
Current
T2-05
Number of motor
poles
Sets the number of motor poles.
2 to 48
poles
4 poles No - - - Yes 734H 4-4
Number of Poles
T2-08
Motor voltage
constant k
e
Sets the motor voltage constant
if T2-99 was set to 0 before.
(Otherwise this parameter is not
displayed)
50.0 to
2000.0
239.3
mVsec/
rad
No - - - Yes 737H 4-4
Voltage constant
T2-09
Number of PG
pulses
Sets the number of PG pulses
per revolution.
512,
1024
*2
or 2048
*2. Can be set only if HIPEFACE
y
is selected as encoder type.
2048 No - - - Yes 738H 4-4
PG Pulses/Rev
T2-10
Motor voltage
constant calcula-
tion selection
Selects if the voltage constant is
calculated during auto tuning or
if it has to input manually.
0:Manual input in parameter
T2-08
1:Automatic calculation
0 or 1 1 No - - - Yes 72FH 4-4
VoltConst-
CalcSel
