Omron VARISPEED L7 User Manual

5-62
5
200 V and 400 V Class Inverters of 3.7 to 45 kW*
200 V and 400V Class Inverters of 55 kW*
Para
meter
Num-
ber
Unit Factory Setting
Open
Loop
Vector
Con-
trol
Closed
Loop
Vector
Con-
trol
Closed
Loop
Vector
(PM)
E1-
03
- 0 1 2 3 4 5 6 7 8 9 A B C D E F
E1-04
Hz 50.0 60.0 60.0 72.0 50.0 50.0 60.0 60.0 50.0 50.0 60.0 60.0 90.0 120.0 180.0 50.0 50.0 50.0 -
rpm---------------- - -150
E1-05
*1
*1. The settings shown are for 200 V class Inverters. The values will double for 400 V class Inverters.
V 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 190.0 190.0 190.0 200.0
E1-06
Hz 50.0 60.0 50.0 60.0 50.0 50.0 60.0 60.0 50.0 50.0 60.0 60.0 60.0 60.0 60.0 50.0 50.0 50.0 -
rpm---------------- - -150
E1-07
*1
Hz 2.5 3.0 3.0 3.0 25.0 25.0 30.0 30.0 2.5 2.5 3.0 3.0 3.0 3.0 3.0 3.0 3.0 - -
rpm---------------- - - -
E1-08
*1
V 14.0 14.0 14.0 14.0 35.0 50.0 35.0 50.0 18.0 23.0 18.0 23.0 14.0 14.0 14.0 18.6 12.5 - -
E1-09
Hz 1.3 1.5 1.5 1.5 1.3 1.3 1.5 1.5 1.3 1.3 1.5 1.5 1.5 1.5 1.5 0.5 0.3 0.0 -
rpm---------------- - - 0
E1-10
*1
V 7.0 7.0 7.0 7.0 6.0 7.0 6.0 7.0 9.0 11.0 9.0 13.0 7.0 7.0 7.0 9.7 2.5 - -
E1-13 V 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 200.0
Para
meter
Num-
ber
Unit Factory Setting
Open
Loop
Vector
Con-
trol
Closed
Loop
Vector
Con-
trol
Closed
Loop
Vector
(PM)
E1-
03
- 0 1 2 3 4 5 6 7 8 9 A B C D E F
E1-04
Hz 50.0 60.0 60.0 72.0 50.0 50.0 60.0 60.0 50.0 50.0 60.0 60.0 90.0 120.0 180.0 50.0 50.0 50.0 -
rpm---------------- - -150
E1-05
*1
*1. The settings shown are for 200 V class Inverters. The values will double for 400 V class Inverters.
V 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 190.0 190.0 190.0 200.0
E1-06
Hz 50.0 60.0 50.0 60.0 50.0 50.0 60.0 60.0 50.0 50.0 60.0 60.0 60.0 60.0 60.0 50.0 50.0 50.0 -
rpm---------------- - -150
E1-07
*1
Hz 2.5 3.0 3.0 3.0 25.0 25.0 30.0 30.0 2.5 2.5 3.0 3.0 3.0 3.0 3.0 3.0 3.0 - -
rpm---------------- - - -
E1-08
*1
V 12.0 12.0 12.0 12.0 35.0 50.0 35.0 50.0 15.0 20.0 15.0 20.0 12.0 12.0 12.0 16.0 12.5 - -
E1-09
Hz 1.3 1.5 1.5 1.5 1.3 1.3 1.5 1.5 1.3 1.3 1.5 1.5 1.5 1.5 1.5 0.5 0.3 0.0 -
rpm---------------- - - 0
E1-10
*1
V 6.0 6.0 6.0 6.0 5.0 6.0 5.0 6.0 7.0 9.0 7.0 11.0 6.0 6.0 6.0 8.3 2.5 - -
E1-13 V 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 200.0
