Omron VARISPEED L7 User Manual

5-64
5
400 V Class Inverters
Parameter Number Name Unit Factory Setting
- Inverter Capacity kW 3.7 4.0 5.5 7.5 11 15
o2-04 kVA selection - 24 25 26 27 28 29
C6-02 Carrier frequency - 3 3 3 3 3 3
E2-01
(E4-01)
Motor rated current A 7.00 7.00 9.80 13.30 19.9 26.5
E2-02
(E4-02)
Motor rated slip Hz 2.70 2.70 1.50 1.30 1.70 1.60
E2-03
(E4-03)
Motor no-load current A 2.30 2.30 2.60 4.00 5.6 7.6
E2-05
(E4-05)
Motor line-to-line resistance W 3.333 3.333 1.595 1.152 0.922 0.550
E2-06
(E4-06)
Motor leak inductance % 19.3 19.3 18.2 15.5 19.6 17.2
E2-10
Motor iron loss for torque compen-
sation
W 130 130 193 263 385 440
E5-02 PM motor rated power kW 3.70 4.00 5.50 7.50 11.0 15.0
E5-03 PM motor rated current A 7.31 7.31 10.00 14.60 19.0 26.6
E5-04PM number of poles -444444
E5-05 PM motor line-to-line resistance Ohm 1.326 1.326 1.479 0.892 0613 0.378
E5-06 PM d-axis inductance mH 1.911 1.911 2.158 1.433 1.384 0.985
E5-07 PM q-axis inductance mH 26.08 26.08 2.944 1.956 1.983 1.479
E5-09 PM voltage constant mV 4.786 4.786 5.084 4.739 5.400 5.084
L8-02 Overheat pre-alarm level °C909085907390
n5-02 (A1-02=3) Motor acceleration time sec 0.154 0.154 0.168 0.175 0.265 0.244
n5-02 (A1-02=5) Motor acceleration time sec 0.121 0.081 0.081 0.075 0.082 0.099
Parameter Number Name Unit Factory Setting
- Inverter Capacity kW 18.5 22 30 37 45 55
o2-04 kVA selection - 2A 2B 2C 2D 2E 2F
C6-02 Carrier frequency - 3 3 2 2 2 2
E2-01
(E4-01)
Motor rated current A 32.9 38.6 52.3 65.6 79.7 95.0
E2-02
(E4-02)
Motor rated slip Hz 1.67 1.70 1.80 1.33 1.60 1.46
E2-03
(E4-03)
Motor no-load current A 7.8 9.2 10.9 19.1 22.0 24.0
E2-05
(E4-05)
Motor line-to-line resistance W 0.403 0.316 0.269 0.155 0.122 0.088
E2-06
(E4-06)
Motor leak inductance % 20.1 23.5 20.7 18.8 19.9 20.0
E2-10
Motor iron loss for torque compen-
sation
W 508 586 750 925 1125 1260
E5-02 PM motor rated power kW 18.5 22.0 30.0 37.0 45.0 55.0
E5-03 PM motor rated current A 32.5 38.2 51.8 66.6 74.7 90.8
E5-04PM number of poles -444444
E5-05 PM motor line-to-line resistance Ohm 0.276 0.217 0.165 0.107 0.087 0.064
E5-06 PM d-axis inductance mH 0.795 0.680 0.515 0.362 0.359 0.287
E5-07 PM q-axis inductance mH 1.194 1.022 0.800 0.563 0.555 0.444
E5-09 PM voltage constant mV 5.137 5.223 5.208 4.902 5.520 5.544
L8-02 Overheat pre-alarm level °C808072808273
n5-02 (A1-02=3) Motor acceleration time sec 0.317 0.355 0.323 0.320 0.387 0.317
n5-02 (A1-02=5) Motor acceleration time sec 0.098 0.096 0.126 0.124 0.188 0.186
