6-58
6
îš„During Regenerative Operation (Setting: 1D)
If a multifunction output is set to this function, the output is switched ON when the motor works regenerative,
i.e. when energy is fed back to the inverter.
îš„Restart Enabled (Setting: 1E)
Refer to page 6-81, Automatic Fault Reset.
îš„During Torque Limit (Setting: 30)
Refer to page 6-43, Limiting the Motor Torque (Torque Limit Function).
îš„Zero Servo End (Setting: 33)
Refer to page 6-16, Zero Speed Control / Zero Servo (position lock).
îš„Brake Release Command (Setting: 40)
This output signal can be used to control the brake. The output is closed when the brake shall be opened. Refer
also to page 6-13, Brake Sequence.
îš„Motor Contactor Control Command (Setting: 41)
This output can be used to control the motor contactors. The output is closed when the contactors shall be
closed. Refer also to page 6-13, Brake Sequence.
îš„Cooling Fan Running (Setting: 38)
This output can be used to indicate the inverters heatsink cooling fan operation. The output is on if the cooling
fan(s) is (are) on.
îš„Speed Detection at deceleration (Door Zone) (Setting:42)
This output can be used to detect if the car is in the door zone. The detection is speed dependent.
If the Up/Down command is released, this output is switched OFF.
îš„Not Zero Speed (Setting:43)
This function can be used for indicating the inverse condition of the Zero speed status.
îš„Light Load Search End (Setting: 44/45)
Refer to page 6-80, Light Load Direction Detection.
îš„Base Block Monitor 1 and 2 (Setting: 46/47)
If a multifunction output is programmed for this function, the output is switched if both base block inputs (BB
and BB1) are enabled.
V/f control and Open Loop Vector control Closed Loop Vector control
OFF
The output frequency is lower than S1-27 during
deceleration
The motor speed is lower than S1-27 during deceler-
ation
ON
The output frequency is higher than S1-27 during
deceleration
The motor speed is higher than S1-27 during deceler-
ation
OFF The output frequency is lower than the zero speed level.
ON The output frequency is higher than the zero speed level.
