Omron VARISPEED L7 User Manual

1-6
1
 Inverters of 22 kW or More
The external appearance and component names of the Inverter are shown in Fig 1.6. The Inverter with the ter-
minal cover removed is shown in Fig 1.7.
Fig 1.6 Inverter Appearance (22 kW or More)
Fig 1.7 Terminal Arrangement (22 kW or More)
Front cover
Inveter cover
Digital Operator
Terminal cover
Nameplate
Cooling fan
Mounting holes
Control circuit
terminals
Charge indicator
Ground terminals
Main circuit
terminals
