9-3
9
îš„400 V Class
* 1. The maximum applicable motor output is given for a standard 4-pole Yaskawa standard motor. When selecting the actual motor and Inverter, be sure
that the Inverter's rated current is higher than the motor's rated current.
* 2. A transformer with dual star-delta secondary is required on the power supply for 12-pulse-rectification.
Table 9.2 400 V Class Inverters
Model Number
CIMR-L7Z

43P7 44P0 45P5 47P5 4011 4015 4018 4022 4030 4037 4045 4055
Max. applicable motor out-
put (kW)
*1
3.7 4.0 5.5 7.5 11 15 18.5 22 30 37 45 55
Output Rating
Rated output capacity
(kVA)
7 9 12 15 22 28 34 40 54 67 80 106
Rated output current
(A)
8.511141827344148658096128
Max. output voltage
(V)
3-phase; 380, 400, 415, 440, 460, or 480 VAC (Proportional to input voltage.)
Max. output frequency
(Hz)
120 Hz max.
Power supply characteristics
Rated voltage (V)
Rated frequency (Hz)
3-phase, 380, 400, 415, 440, 460 or 480 VAC, 50/60 Hz
Rated input current (A) 10.2 13.2 17 22 32 41 49 58 78 96 115 154
Allowable voltage
fluctuation
+ 10%, - 15%
Allowable frequency
fluctuation
±5%
Mea-
sures for
power
supply
DC reactor Optional Built In
12-phase
rectification
Not possible Possible
