Omron VARISPEED L7 User Manual

10-7
10
E2-07 Motor iron saturation coefficient 1 0.50
E2-08 Motor iron saturation coefficient 2 0.75
E2-09 Monitor mechanical losses 0.0%
E2-10 Motor iron loss for torque compensation
*1
E2-11 Motor rated output power
*1
E2-12 Motor iron saturation coefficient 3 1.30
E3-01 Motor 2 control mode selection 0
E3-02 Motor 2 Max. output frequency (FMAX) 50.00 Hz
E3-03 Motor 2 Max. output voltage (VMAX) 400.0 V
E3-04 Motor 2 Base frequency (FA) 50.00 Hz
E3-05 Motor 2 Mid. output frequency (FB)
*1
E3-06 Motor 2 Mid. output frequency voltage (VB)
*1
E3-07 Motor 2 Min. output frequency (FMIN)
*1
E3-08 Min. output frequency voltage (VMIN)
*1
E4-01 Motor 2 rated current
*1
E4-02 Motor 2 rated slip
*1
E4-03 Motor 2 no-load current
*1
E2-04 Motor 2 number of motor poles 4
E4-05 Motor 2 line-to-line resistance
*1
E4-06 Motor 2 leak inductance
*1
E4-07 Motor 2 iron saturation coefficient 1
*1
E5-02 PM motor rated power
*1
E5-03 PM motor rated current
*1
E5-04 PM motor number of poles 4 poles
E5-06 PM motor d-axis inductance
*1
E5-07 PM motor q-axis inductance
*1
E5-09 PM Motor voltage constant
*1
F1-01 PG constant 1024
F1-02 Operation selection at PG open circuit (PGO) 1
F1-03 Operation selection at overspeed (OS) 1
F1-04 Operation selection at deviation 3
F1-05 PG rotation 0
F1-06 PG division rate (PG pulse monitor) 1
F1-08 Overspeed detection level 115%
F1-09 Overspeed detection delay time 0.0 sec.
F1-10 Excessive speed deviation detection level 10%
F1-11 Excessive speed deviation detection delay time 0.5 sec.
F1-12 Number of PG teeth 1 0
F1-13 Number of PG teeth 2 0
F1-14 PG open-circuit detection delay time 1.0 sec.
F1-18 DV3 fault detection selection 1
F1-19 DV4 fault detection selection 1024
F1-21 Absolute encoder resolution 2
F1-22 Magnet position offset 60 deg
F1-24 PGO Detection level at stop 20%
F1-25 Encoder copy function selection 0
No. Name
Factory
Setting
Setting
