Omron VARISPEED L7 User Manual

2-7
2
L7Z4015
R/L1, S/L2, T/L3, , 1, 2, B1, B2,
U/T1, V/T2, W/T3, NO, PO
M5 2.5
10
(8 to 6)
10
(8)
Power cables,
e.g., 600 V vinyl
power cables
M5
(M6)
2.5
(4.0 to 5.0)
6 to 10
(10 to 6)
6
(10)
L7Z4018
R/L1, S/L2, T/L3, , 1, 2, U/T1, V/T2,
W/T3, NO
M6 4.0 to 5.0
10 to 35
(8 to 2)
10
(8)
B1, B2, PO M5 2.5
10
(8)
10
(8)
M6 4.0 to 5.0
10 to 25
(8 to 4)
10
(8)
L7Z4022
R/L1, S/L2, T/L3, , 1, 3, U/T1, V/T2,
W/T3, R1/L11, S1/L21, T1/L31, NO, PO
M6 4.0 to 5.0
16
(6 to 4)
16
(6)
M8 9.0 to 10.0
16 to 35
(6 to 2)
16
(6)
L7Z4030
R/L1, S/L2, T/L3, , 1, 3, U/T1, V/T2,
W/T3, R1/L11, S1/L21, T1/L31, NO, PO
M6 4.0 to 5.0
25
(4)
25
(4)
M8 9.0 to 10.0
25 to 35
(4 to 2)
25
(4)
L7Z4037
R/L1, S/L2, T/L3, , 1, U/T1, V/T2, W/T3,
R1/L11, S1/L21, T1/L31, NO
M8 9.0 to 10.0
25 to 50
(4 to 1/0)
35
(2)
3, PO
M6 4.0 to 5.0
10 to 16
(8 to 4)
-
M8 9.0 to 10.0
25 to 35
(4 to 2)
25
(4)
L7Z4045
R/L1, S/L2, T/L3, , 1, U/T1, V/T2, W/T3,
R1/L11, S1/L21, T1/L31, NO
M8 9.0 to 10.0
35 to 50
(2 to 1/0)
35
(2)
3, PO
M6 4.0 to 5.0
10 to 16
(8 to 4)
-
M8 9.0 to 10.0
25 to 35
(4 to 2)
25
(4)
L7Z4055
R/L1, S/L2, T/L3, , 1, U/T1, V/T2,
W/T3, R1/L11, S1/L21, T1/L31, NO
M8 9.0 to 10.0
50
(1 to 1/0)
50
(1)
3, PO
M6 4.0 to 5.0
10 to 16
(8 to 4)
-
M8 9.0 to 10.0
25 to 35
(4 to 2)
25
(4)
*1. The wire size is valid for PVC insulated copper cable, 30° ambient temperature
Inverter
Model
CIMR-

Terminal Symbol
Terminal
Screws
Tightening
Torque
(N•m)
Possible
Wire Sizes
mm
2
(AWG)
Recom-
mended
Wire Size
*1
mm
2
(AWG)
Wire Type
