Omron VARISPEED L7 User Manual

5-11
5
Timer Function: b4
Dwell Functions: b6
Torque Monitor: b8
Param
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
Open
Loop
Vector
Closed
Loop
Vector
Closed
Loop
Vector
(PM)
Display
b4-01
Timer function
ON-delay time
Sets the timer function output ON-
delay time (dead band) for the timer
function input, in 1-second units.
Enabled when a timer function is set
in H1- or H2-.
0.0 to
300.0
0.0 s No A A A A 1A3H 6-52
Delay-ON
Timer
b4-02
Timer function
OFF-delay
time
Sets the timer function output OFF-
delay time (dead band) for the timer
function input, in 1-second units.
Enabled when a timer function is set
in H1- or H2-.
0.0 to
300.0
0.0 s No A A A A 1A4H 6-52
Delay-OFF
Timer
Param
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
Open
Loop
Vector
Close
d Loop
Vector
Closed
Loop
Vector
(PM)
Display
b6-01
Dwell fre-
quency at start
The dwell function can be used to
hold the output frequency tempo-
rarily.
0.0 to
120.0
0.0 Hz No A A A A 1B6H 6-22
Dwell Ref @
Start
b6-02
Dwell time at
start
0.0 to
10.0
0.0 s No A A A A 1B7H 6-22
Dwell Time
@ Start
b6-03
Dwell fre-
quency at stop
0.0 to
120.0
0.0 Hz No A A A A 1B8H 6-22
Dwell Ref @
Stop
b6-04
Dwell time at
stop
0.0 to
10.0
0.0 s No A A A A 1B9H 6-22
Dwell Time
@ Stop
Param
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
Open
Loop
Vector
Close
d Loop
Vector
Closed
Loop
Vector
(PM)
Display
b8-17
Torque monitor
gain
0 to
2.00
1.00 No - - - A 1F9H 6-22
Torque Mon
Gain
Run command
Output frequency
Time
ON
b6-03
OFF
b6-01
b6-04
b6-02
