65
ZN
System Manual
Section 4 APPENDICES
Section 4
Specifications and Dimensions
Clean Monitoring System
Item ZN-SFW11 ZN-SFW12
Power supply voltage Supplied from ZN-PDA
Current consumption 45 mA with 24 VDC without Amplifier Unit
Available Sensor Amplifier ZX series, ZJ-SD series, ZN-PD series
Available Sensor Amplifier
software version
ZX-LDA__-N V1,000 or higher
ZX-EDA__ V1,300 or higher
ZX-TDA__ V1,100 or higher
ZX-SDA__ V1,000 or higher
ZX-PDA__ V1,000 or higher
Available number of connected
Sensor Amplifiers
10 max. (for ZN-PDA)
Indicator Power: green
Sensor communications busy: green
Sensor communications error: red
Serial communications: green
Serial communications error: red
Power (POWER: green)
Serial communications (STA1: green)
Not Clean (OPE1: orange)
Clean (OPE2: green)
Functions - Air Clean Unit automatic control
(multiple unit system control)
Air Clean Unit air level change
Communication
Port RS-232C (9-pin D-sub connector)
Protocol CompoWay/F
Baud rate 38400 bps
Data configuration Data bits: 8, Parity: none, Start bits: 1, Stop bits: 1, Flow control: none
For external
device 2
- Unique communication specification
(RJ-45 connector and straight wiring
LAN cable)
Ambient temperature Operating: 0 to 40°C, Storage: -15 to +50°C (with no icing or condensation)
Ambient humidity Operating and storage: 35 to 85% (with no condensation)
Insulation resistance 20 MΩ at 500 VDC
Dielectric strength 1,000 VAC, 50/60 Hz for 1 min
Vibration resistance 10 to 150 Hz, 0.7-mm double amplitude 80 min each in X, Y and Z directions
Shock resistance 300 m/s
2
3 times each in six directions (up/down, left/right, forward/backward)
Connection method - Connector cable
(standard cable length: 2 m)
Materials Case: PBT (polybutylene terephthalate), Cover: polycarbonate
Weight (packed state) Approx. 100 g (approx. 480 g) Approx. 200 g (approx. 550 g)
Accessories CD-ROM (Realtime Clean Air Monitor), Instruction sheet, two clamps
4append.fm65ページ２００７年６月２８日 木曜日 午前９時１８分
