CHECKING CONNECTING
ROD
BEARING
'
CLEARANCE
WITH
PLASTIGAUGE
Q
1.
Make certain that all parts are marked or identified
so
they are installed in their original positions. Using
a clean dry cloth, thoroughly clean all oil from
crankshaft journal and connecting rod. If connecting
rod bearing inserts are being replaced
(P224
only),
install them in rod and cap.
2.
Place a piece of correct size Plastigauge in the
bearing cap the full width
of
the journal surfaceand
about
1 /4
inch
(6.35
mm)
off
center (Figure
24).
3.
Rotate the crankshaft about
30
degreesfrom bottom
dead center and reinstall the bearing cap; tighten
rod bolts to the torque specified in
ASSEMBLY
TORQUES
AND
SP€C/AL
TOOLS.
Do not turn the
crankshaft.
4.
Remove bearing cap. The flattened Plastigauge will
be found adhering to either the bearing cap or
FIGURE
24.
MEASURING BEARING CLEARANCE
crankshaft.
OIL SEALS
The bearing plate must be removed to replace the oil
Seal (Figure
25).
Drive the
Oil
Seal Out from the inside.
Before installing seals, fill the space between
lips
with a
multi-purpose grease. This will improve sealing.
5.
Compare flattened Plastigauge with the graduations
on Plastigauge envelope to determine clearance.
The number within the matching graduation on the
envelope indicates total clearance in millimeters or
thousandths of an inch.
When installing the gear cover oil seal, tap the seal
inward until
it
is
,645
inch
(16.4
mm)from thefront of the
gear cover.
When installing the bearing plate oil seal, tap the seal
into the bearing plate bore to bottom against the
shoulder in the plate bore. Use aseal expander or place
a piece
of
heavy paper around the end of the crankshaft,
when replacing the bearing plate to avoid damaging the
seal. Remove the paper as soon as the plate
is
in place.
REAR BEARING PLATE
/
"
'
SHOULD
BE CLEANED
OF
ALL
GEAR COVER
OLD
SEALING COMPOUND
BEFORE INSTALLING
SEAL
THIS SURFACE SHOULD BE
CLEANED OF ALL OLD
SEALING COMPOUND
BEFORE INSTALLING SEAL
\
DRIVE
OR
PRESS OIL
SEAL
TO
SHOULDER
OF
THE PLATE BORE
GEAR COVER
OIL
SEAL
REAR BEARING PLATE
OIL SEAL
LS-1163
FIGURE
25.
GEAR COVER
AND
REAR BEARING PLATE OIL SEALS
10-15
