Onkyo A-9070 User Manual

5
En
Features
• (North American models) 140 W/Ch (4 ohm, 20 Hz - 20 kHz, 0.05%, 2 Channels Driven, FTC)
• (European models) 140 W/Ch (4 ohm, 20 Hz - 20 kHz, 0.05%, 2 Channels Driven, IEC)
• A WRAT (Advanced Wide Range Amplifier Technology)
• DIDRC (Dynamic Intermodulation Distortion Reduction Circuitry)
• Parallel Push-Pull Amplification Design with Three-Stage Inverted Darlington Circuitry
• Symmetrical Layout of Power Stage
• Four Large 15,000 µF Capacitors
• Side-mounted Circuit Board Construction to Reduce Vibration
• Separate Digital/Analog Circuitry
• Low-noise Static Display
• PLL Ultra-Low Jitter Technology
• Separate Wolfson 192 kHz/24-Bit DACs (WM8742) for L/R Channels
• Direct Mode
• Tone Control (Bass/Treble)
• Balance Control
• Independent Headphone Amplifier
• Discrete Phono Equalizer
• Phono Input (MM/MC)
• De-emphasis Function
*1
• 3 Digital Inputs (2 Coaxial and 1 Optical)
• Gold-Plated, Machined Solid Brass RCA Inputs
• Gold-plated, Color-coded, Transparent Speaker Posts
• Display Dimmer (Normal/Dim)
*1
This function only applies to the following sampling rates: 32 kHz, 44.1 kHz, 48 kHz. Other rates are not supported.

Onkyo A-9070 Specifications

General

Damping factor	130
Amplifier class	-
Input sensitivity	150 mV
Audio output channels	2.0 channels
Peak power per channel	140 W
Signal-to-Noise Ratio (SNR)	107 dB
Total Harmonic Distortion (THD)	0.006 %
Dynamic power per channel (3 Ohm)	230 W
Dynamic power per channel (4 Ohm)	180 W
Dynamic power per channel (8 Ohm)	100 W
AC (power) in	Yes
Headphone connectivity	6.3 mm
Speakers connectivity type	RCA
Purpose	Home
Product color	Black
Volume control	Rotary
Cables included	AC
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	290 W

Weight and Dimensions

Depth	431 mm
Width	435 mm
Height	174.5 mm
Weight	18100 g
