Onkyo HT-R410 User Manual

34
Using the remote controller with your other AV components
Manufacturer TV VCR DVD Cable Satellite
AIWA 137
AKAI 227
DENON 302
ECHOSTAR 500
EMERSON 228
FISHER 200 100, 101, 102, 140
GE 103, 104
GE • PANA 201, 202
GE • RCA 203
GEMINI 401
GENERAL INSTRUMENT 501
G.I. 400
GO VIDEO 105, 106, 107
GOLD STAR 204, 205 108
HAMLIN 402, 403, 404, 405
HITACHI 206, 207 103, 109 303 502
HUGHES NETWORK SYSTEM 503
JERROLD 406, 407, 408,
409, 410, 411,
412, 413, 414
JVC 208 110, 111, 112, 113 304
KENWOOD 305
MACOM 415, 416, 417
MAGNAVOX 209, 210 114, 115, 116 306 418
MARANTZ 211 307
MITSUBISHI 117, 118, 119, 308
120, 121, 139
NEC 136
OAK 419, 420, 421
ONKYO 301, 313,
316 (for z DVD),
300 (for CD)
PANASONIC 212, 213 122, 123 309 422, 423 504, 505, 506
PHILIPS 214 114 424, 425, 426,
427, 428, 429
PIONEER 215 310 430, 431
PRIMESTAR 507
PROSCAN 216 311 508, 509, 510
RCA 217, 218, 219, 109 311 508, 509, 510
220, 229, 230
S.ATLANTA 432, 433, 434
SAMSUNG 221, 222 124, 125, 126 304 435
SHARP 223 127, 128
SHINTOM 138
SONY 224 129, 130, 131, 312 511
132, 133, 141
TOCOM 436
TOSHIBA 134 313 512
YAMAHA 314
ZENITH 225, 226 135 315 437, 438

Onkyo HT-R410 Specifications

Amplifier Section

Power Output Front L/R Speakers	100 Watts per channel min. RMS at 8 ohms 2 channel driven, 20-20, 000 Hz, 0.08% THD
Power Output Center Speaker	100 Watts min. RMS at 8 ohms, 20-20, 000 Hz, 0.08% THD
Power Output Surround L/R Speakers	100 Watts per channel min. RMS at 8 ohms 2 channel driven, 20-20, 000 Hz, 0.08% THD
Dynamic Power Output at 3 ohms	230 watts × 2
Dynamic Power Output at 4 ohms	170 watts × 2
Dynamic Power Output at 8 ohms	115 watts × 2

Input and Output Impedance

Digital Input Optical	0.5 Vp-p, 75 ohms
Digital Input Coaxial	0.5 Vp-p, 75 ohms
Line Input (CD, VIDEO 1, 2, 3, TAPE)	200 mV, 47 kohms
Multichannel Input (DVD FRONT L/C/R, SURR L/R)	200 mV, 47 kohms
Multichannel Input (SUBWOOFER)	36 mV, 47 kohms
Output Level Rec out (TAPE, VIDEO 1)	200 mV, 470 ohms
Output Level Pre out (SUBWOOFER)	1 V, 470 ohms

Tuner Section

FM Tuning Range	87.5-108.0 MHz (100 kHz steps)
FM Usable Sensitivity Mono	11.2 dBf, 1.0 µV (75 ohms, IHF)
FM Usable Sensitivity Stereo	17.2 dBf, 2.0 µV (75 ohms, IHF)
FM 50 dB Quieting Sensitivity Mono	17.2 dBf, 2.0 µV (75 ohms)
FM 50 dB Quieting Sensitivity Stereo	37.2 dBf, 20.0 µV (75 ohms)
FM Capture Ratio	2.0 dB
FM Image Rejection Ratio	40 dB
FM IF Rejection Ratio	90 dB
FM Signal-to-Noise Ratio Mono	76 dB, IHF
FM Signal-to-Noise Ratio Stereo	70 dB, IHF
FM Alternate Channel Attenuation	55 dB, IHF, ±400 kHz
FM Selectivity	50 dB (DIN)
FM AM Suppression Ratio	50 dB
FM Total Harmonic Distortion Mono	0.2%
FM Total Harmonic Distortion Stereo	0.3%
FM Frequency Response	30 Hz-15 kHz, ±1.0 dB
FM Stereo Separation at 1 kHz	45 dB
FM Stereo Separation at 100 Hz-10 kHz	30 dB
AM Tuning Range	530-1, 710 kHz (10 kHz steps)
AM Usable Sensitivity	30 µV
AM Image Rejection Ratio	40 dB
AM IF Rejection Ratio	40 dB
AM Signal-to-Noise Ratio	40 dB
AM Total Harmonic Distortion	0.7%

General Specifications

Power Supply	AC 120 V, 60 Hz
Power Consumption	4.7 A
Dimensions (W × H × D)	17-1/8” × 5-7/8” × 14-3/8”
Dimensions in mm (W × H × D)	435 × 150 × 365 mm
Weight	19.0 lbs., 8.6 kg
