Onkyo R-N855 User Manual

En- 17
Spotify
Spotify Connect play is possible by connecting this unit to
the same network as a smartphone or tablet. To enable
Spotify Connect, install the Spotify application on your
smartphone or tablet and create a Spotify premium
account.
1. Connect the smartphone to the network that this unit is
connected to.
2. Click the Connect icon in the track play screen of the
Spotify app.
3. Select this unit.
0 This unit is displayed as “Onkyo R-N855 XXXXXX”.
4. This unit turns on automatically and the input selector
changes to NET and streaming of Spotify starts.
0 If “Option” - “PWR Setting” - “NET Stby” is set to
“Off” in the setup menu, manually turn the unit on
and then press NETWORK on the remote controller.
0 Refer to the following for Spotify settings:
www.spotify.com/connect/
0 The Spotify software is subject to third party licenses
found here:
www.spotify.com/connect/third-party-licenses
The following remote controller operations are also
possible.
(a) Start shuffle play.
(b) Pause play.
(c) Play the previous track.
(d) Start repeat play.
(e) Start play.
(f) Play the next track.
Wi-Fi
OnkyoR-N855xxxxxx
a
b
d
c
e
f
SN29402579_R-N855_En_1608xx.book 17 ページ ２０１６年９月１３日 火曜日 午前９時１２分

Onkyo R-N855 Specifications

General

Receiver type	stereo
Frequency range	5 - 60000 Hz
Input sensitivity	200 mV
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	106 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (20-20KHz@8 Ohm)	- W
Audio (L/R) in	2
Digital audio optical in	-
Audio (L/R) out	1
Headphone connectivity	3.5 mm
Product color	Black
Speakers connectivity type	Banana connector
FM band range	87.5 - 108 MHz
Supported radio bands	DAB, DAB+, FM
Preset stations quantity	40
AC input voltage	80-230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	60 W
Package weight	8000 g
Cables included	AC

Weight and Dimensions

Depth	283.2 mm
Width	275 mm
Height	87.7 mm
Weight	6100 g
