Onkyo R-N855 User Manual

En- 21
BLUETOOTH
®
Pairing
1. Turn the unit on.
2. When you press BLUETOOTH, “Now Pairing...” is
displayed on the display, and the pairing mode is
enabled.
3. Enable (turn on) the BLUETOOTH function of the
BLUETOOTH enabled device, then select this unit
from amongst the devices displayed. If a password is
requested, enter “0000”.
0 This unit is displayed as “Onkyo R-N855 XXXXXX”.
4. “Now Pairing...” on the display changes to the name of
the BLUETOOTH enabled device.
0 To connect another BLUETOOTH enabled device,
press and hold BLUETOOTH until “Now Pairing...” is
displayed, then perform step 3 above. This unit can
store the data of up to eight paired devices.
0 The coverage area is 15 meters. Note that connection
is not always guaranteed with all BLUETOOTH
enabled devices.
Playing back
1. Turn the unit on.
2. Perform the connection procedure on the
BLUETOOTH enabled device.
3. The input selector on this unit automatically switches
to “BLUETOOTH”.
4. Play the music files. Increase the volume of the
BLUETOOTH enabled device to an appropriate level.
0 Due to the characteristics of BLUETOOTH wireless
technology, the sound produced on this unit may
slightly be behind the sound played on the
BLUETOOTH enabled device.
Now Pairing...
OnkyoR-N855xxxxxx
OnkyoR-N855xxxxxx
SN29402579_R-N855_En_1608xx.book 21 ページ ２０１６年９月１３日 火曜日 午前９時１２分

Onkyo R-N855 Specifications

General

Receiver type	stereo
Frequency range	5 - 60000 Hz
Input sensitivity	200 mV
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	106 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (20-20KHz@8 Ohm)	- W
Audio (L/R) in	2
Digital audio optical in	-
Audio (L/R) out	1
Headphone connectivity	3.5 mm
Product color	Black
Speakers connectivity type	Banana connector
FM band range	87.5 - 108 MHz
Supported radio bands	DAB, DAB+, FM
Preset stations quantity	40
AC input voltage	80-230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	60 W
Package weight	8000 g
Cables included	AC

Weight and Dimensions

Depth	283.2 mm
Width	275 mm
Height	87.7 mm
Weight	6100 g
