Onkyo R-N855 User Manual

En- 33
“Network” on the display.
6. Press / and ENTER to select “Update” - “via USB”
in order.
0 “Update” is not displayed if there are no firmware
updates.
7. Press ENTER to start the firmware update.
0 “Completed” is displayed when the update is
complete.
8. Press Í to switch the unit to standby. The process is
completed and your firmware is updated to the latest
version.
9. Remove the USB storage device from this unit.
If an error message is displayed : When an error
occurs, “ ＊ - ＊＊ Error!” is displayed on the display of
this unit. Check the following:
0 ＊ -01, ＊ -10 : USB storage device not found. Check
whether the USB storage device or USB cable is
correctly inserted to the USB port of this unit.
Connect the USB storage device to an external power
source if it has its own power supply.
0 ＊ -05, ＊ -13, ＊ -20, ＊ -21 : The firmware file is not
present in the root folder of the USB storage device, or
the firmware file is for another model. Retry from the
download of the firmware file.
0 Others : Disconnect then reconnect the power cord,
then repeat from the beginning.
Network
Update
SN29402579_R-N855_En_1608xx.book 33 ページ ２０１６年９月１３日 火曜日 午前９時１２分

Onkyo R-N855 Specifications

General

Receiver type	stereo
Frequency range	5 - 60000 Hz
Input sensitivity	200 mV
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	106 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (20-20KHz@8 Ohm)	- W
Audio (L/R) in	2
Digital audio optical in	-
Audio (L/R) out	1
Headphone connectivity	3.5 mm
Product color	Black
Speakers connectivity type	Banana connector
FM band range	87.5 - 108 MHz
Supported radio bands	DAB, DAB+, FM
Preset stations quantity	40
AC input voltage	80-230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	60 W
Package weight	8000 g
Cables included	AC

Weight and Dimensions

Depth	283.2 mm
Width	275 mm
Height	87.7 mm
Weight	6100 g
