Opengear ACM7000 User Manual

User Manual
NOTE The Retrieve Hosts function auto-configures all classes of user (i.e. they can be members of
user or admin or some other group or no group). SDT Connector will not auto-configure the root
5.2.3 Make an SDT connection through the gateway to a host
Point at the host to be accessed and click on the service to be used in accessing that host. The SSH
tunnel to the gateway is established, the appropriate ports redirected through to the host, and the
appropriate local client application is launched pointing at the local endpoint of the redirection:
NOTE The SDT Connector client can be configured with unlimited number of Gateways. Each Gateway
can be configured to port forward to an unlimited number of locally networked Hosts. There is no
limit on the number of SDT Connector clients who can be configured to access the one Gateway.
Nor are there limits on the number of Host connections that an SDT Connector client can
concurrently have open through the one Gateway tunnel.
5.2.4 Manually adding hosts to the SDT Connector gateway
For each gateway, you can specify the network connected hosts to be accessed through that console
server; and for each host, specify the services used in communicating with the host
1. Select the newly added gateway and click the Host icon to create a host to be accessible via
this gateway. Or select File > New Host.

Opengear ACM7000 Specifications

General

RS-232 ports	8
SIM card slot	Yes
USB 2.0 ports quantity	4
Number of simultaneous SIM cards	2
Certification	EN 55022:2010, CISPR 22:2008, FCC Part 15 B:2015, ICES-003 5 (2014), AS/NZS CISPR 22:2009+A1:2010, EN 61000-3-2:2006/A2:2009, EN 61000-3-3:2008 EN 55024:2010, CISPR 24:2010, EN 61000-4-2:2009, EN 61000-4-3:2006+A2:2010, EN 61000-4-4:2004+A1:2010, EN 61000-4-5:2006, EN 61000-4-6:2009, EN 61000-4-8:2010, EN 61000-4-11:2004 CE, UL 1950, TUV, C-Tick, RoHS
Mounting type	Rack mounting
Product color	Black, Red
Antenna connector type	SMA
Flash memory	32 MB
Internal memory	256 MB
Processor frequency	800 MHz
Control display unit	No
Internal memory type	DDR3
Input voltage	110 - 240 V
DC input voltage	12 V
Storage temperature (T-T)	-40 - 75 °C
Operating temperature (T-T)	-25 - 60 °C
Operating relative humidity (H-H)	5 - 90 %
Security algorithms	IPSec, SSH-2, SSL/TLS

Weight and Dimensions

Depth	120 mm
Width	130 mm
Height	35 mm
Weight	6000 g
