Opengear ACM7000 User Manual

225
APPENDIX A: Hardware Specification
FEATURE
VALUE
Dimensions
ACM7004, ACM7004-2-L(V/A/R/MA/MV/MCR/MCT): 5 1/8 x
4 3/4 x 1 3/8 in (13 x 12 x 3.5 cm)
IM7216/32/48: 17 x 10 x 1.75 in (44 x 25.4 x 4.5 cm)
CM7116/32/48: 17 x 6.9 x 1.75 in (44 x 17 x 4.5 cm)
Weight
ACM7004, ACM7004-2-L(V/A/R/MA/MV/MCR/MCT): 0.6kg
(1.3 lbs)
IM7216/32/48: 4.5 kg (10 lbs)
CM7116/32/48: 4 kg (9 lbs)
Ambient operating
temperature
5°C to 50°C (41°F to 122°F) Higher for -I models
Non-operating storage temp
-30°C to +60°C (-20°F to +140°F)
Humidity
5% to 90%
Power
IM7200, CM7100: DAC have dual socket 100-240V AC
DDC models dual +/- 36V to 72V DC
Power consumption of IM7216-24E – 40W
CM7100: SAC models – single socket universal 100-240V AC
ACM7000: 110-240V AC to 12V DC external power adapter
Power Consumption
All less than 30W
CPU
IM7200: 1GHz ARM SoC (Marvell 88F6283)
CM7100: 800MHz ARM SoC (Marvell 88F6W11)
ACM7000: 800MHz ARM SoC (Marvell 88F6W11)
Others: Micrel KS8695P controller
Memory
ACM7004, ACM7004-2-L(V/A/R/MA/MV/MCR/MCT): 254MB
SDRAM, 256MB + 4GB Flash
IM7216/32/48: 256MB SDRAM, 64MB + 16 GB Flash
CM7116/32/48: 256MB SDRAM, 32MB + 4GB Flash
USB ports
ACM7004, ACM7004-2-L(V/A/R/MA/MV/MCR/MCT): 4
external USB2.0
IM7216/32/48: 2 external USB3.0
CM7116/32/48: 2 external USB2.0
Serial Connectors
ACM7004, ACM7004-2-L(V/A/R/MA/MV/MCR/MCT): 4 RJ-
45 RS-232 serial ports
IM7216-2: 16 RJ-45 RS-232 serial ports **
IM7232-2: 32 RJ-45 RS-232 serial ports **
IM7248-2: 48 RJ-45 RS-232 serial ports**
CM7116-2: 16 RJ-45 RS-232 serial ports **
CM7132-2: 32 RJ-45 RS-232 serial ports **
CM7148-2: 48 RJ-45 RS-232 serial ports **
* models also have 1 DB-9 RS-232 console / modem serial
port
** models also have 1 RJ45 console port
Serial Baud Rates
RJ45 ports - 50 to 230,400bps
DB9 port - 2400 to 115,200 bps
Ethernet Connectors
IM7216/32/48: Two 10/100/1000 GbE copper or SFP fiber
ports
ACM7004, ACM7004-2-L(V/A/R/MA/MV/MCR/MCT): Two
10/100/1000 GbE ports
CM7116/32/48: Two 10/100/1000 GbE ports

Opengear ACM7000 Specifications

General

RS-232 ports	8
SIM card slot	Yes
USB 2.0 ports quantity	4
Number of simultaneous SIM cards	2
Certification	EN 55022:2010, CISPR 22:2008, FCC Part 15 B:2015, ICES-003 5 (2014), AS/NZS CISPR 22:2009+A1:2010, EN 61000-3-2:2006/A2:2009, EN 61000-3-3:2008 EN 55024:2010, CISPR 24:2010, EN 61000-4-2:2009, EN 61000-4-3:2006+A2:2010, EN 61000-4-4:2004+A1:2010, EN 61000-4-5:2006, EN 61000-4-6:2009, EN 61000-4-8:2010, EN 61000-4-11:2004 CE, UL 1950, TUV, C-Tick, RoHS
Mounting type	Rack mounting
Product color	Black, Red
Antenna connector type	SMA
Flash memory	32 MB
Internal memory	256 MB
Processor frequency	800 MHz
Control display unit	No
Internal memory type	DDR3
Input voltage	110 - 240 V
DC input voltage	12 V
Storage temperature (T-T)	-40 - 75 °C
Operating temperature (T-T)	-25 - 60 °C
Operating relative humidity (H-H)	5 - 90 %
Security algorithms	IPSec, SSH-2, SSL/TLS

Weight and Dimensions

Depth	120 mm
Width	130 mm
Height	35 mm
Weight	6000 g
