Opengear ACM7000 User Manual

Chapter 9: Nagios Integration
194
9.2 Configuring Nagios distributed monitoring
To activate the console server Nagios distributed monitoring:
§ Nagios integration must be enabled and a path established to the central/upstream Nagios server
§ If the console server is to periodically report on Nagios monitored services, the NSCA client
embedded in the console server must be configured – the NSCA program enables scheduled check-
ins with the remote Nagios server and is used to send passive check results across the network to
the remote server
§ If the Nagios server is to actively request status updates from the console server, the NRPE server
embedded in the console server must be configured – the NRPE server is the Nagios daemon for
executing plug-ins on remote hosts
§ Each of the Serial Ports and each of the Hosts connected to the console server which are to be
monitored must have Nagios enabled and any specific Nagios checks configured
§ Lastly the central/upstream Nagios monitoring host must be configured
9.2.1 Enable Nagios on the console server
1. Select System > Nagios on the console server Management Console and tick the Nagios service
Enabled
2. Enter the Nagios Host Name that the Console server will be referred to in the Nagios central
server – this will be generated from local System Name (entered in System > Administration) if
unspecified
3. In Nagios Host Address enter the IP address or DNS name that the upstream Nagios server will
use to reach the console server – if unspecified this will default to the first network port’s IP
(Network (1) as entered in System > IP)
4. In Nagios Server Address enter the IP address or DNS name that the console server will use to
reach the upstream Nagios monitoring server

Opengear ACM7000 Specifications

General

RS-232 ports	8
SIM card slot	Yes
USB 2.0 ports quantity	4
Number of simultaneous SIM cards	2
Certification	EN 55022:2010, CISPR 22:2008, FCC Part 15 B:2015, ICES-003 5 (2014), AS/NZS CISPR 22:2009+A1:2010, EN 61000-3-2:2006/A2:2009, EN 61000-3-3:2008 EN 55024:2010, CISPR 24:2010, EN 61000-4-2:2009, EN 61000-4-3:2006+A2:2010, EN 61000-4-4:2004+A1:2010, EN 61000-4-5:2006, EN 61000-4-6:2009, EN 61000-4-8:2010, EN 61000-4-11:2004 CE, UL 1950, TUV, C-Tick, RoHS
Mounting type	Rack mounting
Product color	Black, Red
Antenna connector type	SMA
Flash memory	32 MB
Internal memory	256 MB
Processor frequency	800 MHz
Control display unit	No
Internal memory type	DDR3
Input voltage	110 - 240 V
DC input voltage	12 V
Storage temperature (T-T)	-40 - 75 °C
Operating temperature (T-T)	-25 - 60 °C
Operating relative humidity (H-H)	5 - 90 %
Security algorithms	IPSec, SSH-2, SSL/TLS

Weight and Dimensions

Depth	120 mm
Width	130 mm
Height	35 mm
Weight	6000 g
