6 ALERTS, AUTO-RESPONSE & LOGGING
This chapter describes the automated response, alert generation and logging features of the console
server.
With Auto-Response the console server monitors selected serial ports, logins, the power status and
environmental monitors and probes for Check Condition triggers. The console server initiates a sequence
of actions in response to these triggers. To configure Auto-Response:
1. Set the general parameters
2. Select and configure the Check Conditions, the conditions that trigger the response.
3. Specify the Trigger Actions, the sequence of actions initiated in event of the trigger condition.
4. Specify the Resolve Actions, the actions performed when trigger conditions have been resolved.
Console servers can maintain log records of all access and communications with the console server and
with the attached serial devices. A log of all system activity is also maintained as is a history of the status
of any attached environmental monitors.
Some models can also log access and communications with network attached hosts and maintain a
history of the UPS and PDU power status.
If port logs are to be maintained on a remote server, the access path to this location need to be configured
Activate and set the desired levels of logging for each serial and/or network port and/or power and
environment UPS.
6.1 Configure Auto-Response
With the Auto-Response facility, a sequence of Trigger Actions is initiated in the event of a specified
trigger condition (Check Condition). Subsequent Resolve Actions can also be performed when the trigger
condition has been resolved.
To configure, set the general parameters that apply to all Auto-Responses:
• Check Log Events on Alerts & Logging > Auto-Response to enable logging all Auto-Response
activities
• Check Delay after Boot to set any general delay to be applied after console server system
boot, before processing events

Opengear ACM7000 Specifications

General

RS-232 ports	8
SIM card slot	Yes
USB 2.0 ports quantity	4
Number of simultaneous SIM cards	2
Certification	EN 55022:2010, CISPR 22:2008, FCC Part 15 B:2015, ICES-003 5 (2014), AS/NZS CISPR 22:2009+A1:2010, EN 61000-3-2:2006/A2:2009, EN 61000-3-3:2008 EN 55024:2010, CISPR 24:2010, EN 61000-4-2:2009, EN 61000-4-3:2006+A2:2010, EN 61000-4-4:2004+A1:2010, EN 61000-4-5:2006, EN 61000-4-6:2009, EN 61000-4-8:2010, EN 61000-4-11:2004 CE, UL 1950, TUV, C-Tick, RoHS
Mounting type	Rack mounting
Product color	Black, Red
Antenna connector type	SMA
Flash memory	32 MB
Internal memory	256 MB
Processor frequency	800 MHz
Control display unit	No
Internal memory type	DDR3
Input voltage	110 - 240 V
DC input voltage	12 V
Storage temperature (T-T)	-40 - 75 °C
Operating temperature (T-T)	-25 - 60 °C
Operating relative humidity (H-H)	5 - 90 %
Security algorithms	IPSec, SSH-2, SSL/TLS

Weight and Dimensions

Depth	120 mm
Width	130 mm
Height	35 mm
Weight	6000 g
