Intersection Equipment Installation Instructions
13
Figure 3-3 shows a radio/GPS unit installed on a span wire pole. The radio/GPS unit should be mounted
level and extended about 3 feet (1m) away from the pole.
Figure 3-3. Span Wire Pole Installation Model 1010
Figure 3-4 shows a Model 1010 radio/GPS unit installed on a span wire. The radio/GPS unit should be
mounted level and higher than the upper span wire. Mount the unit so that it is as rigid and stable as
possible.
Figure 3-4. Span Wire Installation Model 1010
Note: This method should only be used if other methods are not available.
