OPTIMUM
MASCHINEN - GERMANY
Mechanische Ersatzteile - Mechanical Spare parts
Version 1.1.6 2014-10-16 122 Original operating instructions
F150DE | GB
Ersatzteilliste Säule - Spare part list column
Pos.
Bezeichnung Designation
Quan-
tity
Size Item number
Qty. Size Item no.
1 Spindle head Spindle head 1 035112101 01
2 Hexagon socket screw Socket head screw 24 M10xP1.5x45L 035112101 02
3 Hexagon socket screw Socket head screw 4 M5xP0.8x12L 035112101 03
4 Platte Press plate 4 035112101 04
5 Halter Endschalter Bracket of limit switch 1 035112101 05
6 Hexagon socket screw Socket head screw 2 M6xP1.0x12L 035112101 06
7 Endschalter Limit switch 1 035112101 07
8 Hexagon socket screw Socket head screw 2 M6xP1.0x16L 035112101 08
9 Lineare Führung Linear way 2 035112101 09
10 Hexagon socket screw Socket head screw 26 M8xP1.25x30L 035112101 10
11 Hexagon socket screw Socket head screw 26 M6xP1.0x12L 035112101 11
12 Klotz Blocker 26 035112101 12
13 Hexagon socket screw Socket head screw 4 M6xP1.0x12L 035112101 13
14 Hexagon socket screw Socket head screw 6 M6xP1.0x12L 035112101 14
15 Platte Dog 3 035112101 15
16 Halter Platte Dog bracket 1 035112101 16
17 Plate Dog base 1 035112101 17
18 Hexagon socket screw Socket head screw 8 M24xP3.0x70L 035112101 18
19 Column Column 1 035112101 19
