11.18 Externes Kühlaggregat 70 bar - External cooling unit 70 bar
Abb.11-22: Externes Kühlaggregat 70 bar - External cooling unit 70 bar
Ersatzteilliste - Spare parts list
1
2
3
4
5
6
7
8
9
Pos.
Bezeichnung Designation
Menge Grösse Artikelnummer
Qty. Size Item no.
1 Kühlmittelbehälter Tank 1 035112100301
2 Kühlmittelpumpe Vorlauf Inlet pump 1 035112100302
3 Manometer Pressure gauge 1 035112100303
4 Druckschalter Pressure switch 1 035112100304
5 Filter Vorlauf Inlet filter 1 035112100305
6 Filter Rücklauf Outlet filter 1 035112100306
7 Kühlmittelpumpe Rücklauf Outlet pump 1 035112100307
8 Druckventil Pressuge valve 1 035112100308
9 Manometer Pressure gauge 1 035112100309
