Technical data
Version 1.1.6 dated 2014-10-16 Page 23Original operating instructions
F150 GB
2.8 Working area, traverse path
2.9 Standard tool changer carrousel
2.10 Optional tool changer double arm gripper
2.10.1 Standard milling spindle head
X-axis [mm] 760
Y-axis [mm] 430
Z-axis [mm] 460
Max. number of tool places 16
max. tooling diameter [mm] 89
Max. tool weight [kg] 8
Cycle tool change (tool to tool) [sec.] 9
Max. number of tool places 24
max. tooling diameter [mm] 80
Max. tool weight [kg] 8
Cycle tool change (tool to tool) [sec.] 2
Spindle seat
Speed range [ min
-1
] 10 -10000
