OPTIMUM
MASCHINEN - GERMANY
Technical data
Version 1.1.6 dated 2014-10-16 Page 21Original operating instructions
F150 GB
2 Technical data
The following information are the dimensions and indications of weight and the manufacturer‘s
approved machine data.
2.1 Electrical connection
2.2 Lubricant/coolant system
2.3 Compressed air supply
2.4 Dimensions
Total connection 3 x 400V ~ 50Hz 25 kW
Cross section connection cable
according to DIN 5710/VDE 0100
4 x 6 mm
2
Fusing performed by the operator 32 A
Power of the coolant/lubricant pumps [W] 1270
Delivery volume [l/min] 66-100
Tank capacity [l] 210
Connection [MPa] 0,5 - 0,7 (5 - 7 bar), fast locking coupling
Air consumption 0.1 - 0.15 m
3
/ h at 0.6 MPa
Compressed air consumer Tool changer forward / backward
Tool clamp / unclamp
Air purge
Recommended compressed air quality ISO 8573.1 class 2
Height [mm]
"Installation plan F150“ on page 30Depth [mm]
Width [mm]
Total weight [kg] about 3020
Load capacity of the substructure [kN/m
2
]16
