OPTIMUM
MASCHINEN - GERMANY
Notes, messages and error messages
Version 1.1.6 dated 2014-10-16Page 86 Original operating instructions
F150GB
8 Notes, messages and error messages
All messages and alarms are displayed in plain text on the operator panel. The alarm text con-
tains the date, time and a suitable symbol for the cancel criterion.
Alarms and messages are displayed separately according to the following criteria:
Alarms and messages in the part program.
Alarms and messages from the plc and alarms and messages that concern the machine.
The following notes, messages and error messages are the vendor-specific messages of the
machine.
Several messages and error messages are an optional feature of the CNC machine and pro-
vided only active when the CNC machine has these features.
Number Message description
700000 Emergency stop button pressed, release it and press reset on MCP
Possible cause
• Unlock the Emergency stop button and press reset on the machine control panel (MCP).
• Emergency stop button defect and gives an erroneous signal.
700008 Feed not enabled on machine control panel !
Possible cause
and remedy
• Enable feed on machine control panel.
700009 Waiting for spindle up to speed. . .
700010 plc alarm DB1600.DBX1.2
700011 Automatic power off active, servo off!
Effect • Drive off!
700016 Hydraulic pump overloaded.
Possible cause
Motor protection switch of the hydraulic pump is faulty.
Motor protection switch setting faulty.
Hydraulic pump is sucking air.
Clamping pressure / working pressure set too high.
Hydraulic pump or drive motor defective.
700017 Hydraulic pressure not reached.
Possible cause
• Subsequent alarm 700 016
• Pressure too low
• Pressure switch is defective on the hydraulic unit.
700019 T code error.
700020 Tool change error.
700021 Tool change position data loading error.
700022 Axis %D PLC positioning error.
700023 Spindle zero position, check sensor not ON.
700024 Tool clamp / unclamp error.
700025 Arm rotate error.
700026 Tool pocket up/down error.
700027 Tool magazine position error.
