OPTIMUM
MASCHINEN - GERMANY
Version 1.1.6 2014-10-16 142 Original operating instructions
F150DE | GB
10 Nockenscheibe Cam disk 1 0351121013 10
11 Sensorhalter Sensor bracket 1 0351121013 11
12 Welle Shaft 1 0351121013 12
13 Lagerbock Bearing bracket 1 0351121013 13
14 Halter Sensor Holder Sensor 1 0351121013 14
15 Schraube Screw 6 M6
16 Schraube Screw 6 M6
17 Schraube Screw 1 M8
18 Schraube Screw 10 M8
19 Schraube Screw 1 M8
20 Schraube Screw 21 M5
21 Schraube Screw 2 M12
22 Scheibe Washer 3
23 Mutter Nut 3
24 Scheibe Washer 1
25 Mutter Nut 1
26 Scheibe Washer 6 6
27 Scheibe Washer 1 8
28 Sealing ring Sealing ring 2 14
29 Lager Bearing 2 30203 0351121013 29
30 Lager Bearing 2 32008 0351121013 30
31 Nutenstein Sliding block 1 5x30 0351121013 31
32 Nutenstein Sliding block 2 6x40 0351121013 32
33 Gehäuse Getriebe Worm gear 1 0351121013 33
34 Befestigungsarm Fixed arm 1 0351121013 34
35 Motor Motor 1 0351121013 35
36 Deckel Motor Motor box cover 1 0351121013 36
37 Schraube Screw 4 M3
38 Federscheibe Spring washer 4 4
39 Schraube Screw 4 M6
Pos.
Bezeichnung Designation
Quan-
tity
Size Item number
Qty. Size Item no.
