OPTIMUM
MASCHINEN - GERMANY
Version 1.3.0 dated 2016-12-16 Page 17Original operating instructions
MF2 Vario GB
2 Technical data
The following information gives the dimensions and weight and is the manufacturer‘s
authorised machine data.
2.1 Electrical connection
Total connection rate 3 x 400 V; 50 Hz; 1.5 KW
Degree of protection IP 54
2.2 Dimensions
Taper ISO 40 (DIN 2080, DIN 69871)
Spindle sleeve diameter Ø 85.7 mm
Clamping surface of cross table 230 x 1244 mm
Max. dist. from spindle head to table 446 mm
Max. dist. from centre of spindle to upright 680 mm
Min. dist. from centre of spindle to upright 200 mm
Height 2150 mm
Width 1400 mm
Depth 1450 mm
Total weight 900 kg
Max. load of cross table 230 kg
Number of the T-slots 3
Size of the slot nut 16 x 63 mm
Throat depth 213 - 533 mm
2.3 Milling capacity / removal
MF2 Vario
End-milling cutter ø18 6 mm
Face milling cutter ø76 2.5 mm
2.4 Adjustment travels / swiveling range
Spindle sleeve travel 127 mm
Adjustment travel of cross table (X-axis) 800 mm
Adjustment travel of cross table (Y-axis) 305 mm
Vertical adjustment travel of cross table 406 mm
Swivel range spindle head carrier ± 90°
Up/down spindle head inclination ± 45°
