Optimum OPTIMILL MF 2V - 4 Operation; Overview; Operation 4.1 Overview

OPTIMUM
MASCHINEN - GERMANY
Version 1.3.0 dated 2016-12-16 Page 27Original operating instructions
MF2 Vario GB
4 Operation
4.1 Overview
Img.4-1: Overview of the machine
2
11
9
12
4
5
13
6
7
1
3
10
8
Pos. Designation Pos. Designation
1 Spindle head 8 Wheel for cross table (Y-axis)
2 Spindle sleeve lever 9 Control panel
3 Spindle sleeve fine feed 10 Stops
4 Spindle protection 11 Crank handle
5 Cross table 12 Control module for feed motor
6 Crank handle for cross table
(X-axis)
13 Tightening lever for cross table (X-axis)
7 Tightening lever for cross table
Height adjustment
