Oracle Database Appliance X6-2-HA Owner's Guide

Supported Components and Capabilities
Chapter2 • Overview of Oracle Database Appliance 17
Component Oracle Database Appliance
(Version 1)
Oracle Database Appliance
X3-2
Oracle Database Appliance
X4-2
Oracle Database Appliance
X5-2
■ PCIe slot 0: Dual 10
GbE SFP+ PCIe 2.0 Low
Profile Adapter
■ PCIe slot 1: Quad-port 1
GbE (Gigabit Ethernet)
Network Adapter with
RJ-45 connectors
■ PCIe slot 2: Dual-port
External 6Gb/s SAS2
host bus adapter
One internal low-profile
PCIe Gen-2 slot (x8) with
a Dual-port Internal 6Gb/s
SAS2 host bus adapter
■ PCIe slot 1: Dual-port 10
GbE Network Adapter
with RJ-45 connectors
■ PCIe slot 2: Dual-port
External 6Gb/s SAS2
host bus adapter
■ PCIe slot 3: Dual-port
External 6Gb/s SAS2
host bus adapter
■ PCIe Slot 4: Dual-port
Internal 6Gb/s SAS2
host bus adapter
■ PCIe slot 1: Dual 10
GbE SFP+ PCIe 2.0 Low
Profile Adapter
■ PCIe slot 2: Dual-port
External 6Gb/s SAS2
host bus adapter
■ PCIe slot 3: Dual-port
External 6Gb/s SAS2
host bus adapter
■ PCIe slot 4: Dual-port
Internal 6Gb/s SAS2
host bus adapter
PCIe 3.0 Low Profile
Adapter
■ PCIe slot 2: Dual-port
External 12Gb/s SAS3
host bus adapter
■ PCIe slot 3: Dual-port
External 12Gb/s SAS3
host bus adapter
■ PCIe slot 4: Dual-port
Internal 12Gb/s SAS3
host bus adapter
Cluster
device
One integrated cluster
device with node-to-node
connections is provided
on each server node. Each
integrated cluster device
provides two internal 1 GbE
network interface ports and
two internal dual-port UART
ports.
One integrated cluster
device with node-to-node
interconnection is provided
on each server node through
two 10 GbE network
interface ports with RJ-45
connections.
One integrated cluster
device with node-to-node
interconnection is provided
on each server node through
two 10 GbE network
interface ports with dual-rate
SFP+ connections.
Alternatively, you have the
option of creating the node-
to-node interconnection
using two of each server
node's four 10 GbE network
interface ports with RJ-45
connections. Refer to the
Oracle Database Appliance
Getting Started Guide for
more information.
One integrated cluster
device with node-to-node
interconnection is provided
on each server node through
two InfiniBand ports with
QSFP+ connections.
Alternatively, you have the
option of creating the node-
to-node interconnection
using two of each server
node's four 10 GbE network
interface ports with RJ-45
connections. Refer to the
Oracle Database Appliance
Getting Started Guide for
more information.
SAS ports N/A Two internal SAS2 and four
external SAS2 ports on each
server node.
Six SAS2 ports on the
storage shelf.
Six SAS2 ports on the
storage expansion shelf.
Two internal SAS2 and four
external SAS2 ports on each
server node.
Six SAS2 ports on the
storage shelf.
Six SAS2 ports on the
storage expansion shelf.
Two internal SAS3 and four
external SAS3 ports on each
server node.
Six SAS2 ports on the
storage shelf.
Six SAS2 ports on the
storage expansion shelf.
Onboard
Ethernet
ports
Two 1 GbE network
interface ports with RJ-45
connectors located on the
back panel of each server
node.
Four auto-sensing
100/1000/10000 Base-T
Ethernet ports with RJ-45
connectors located on the
back of each server node.
Four auto-sensing
100/1000/10000 Base-T
Ethernet ports with RJ-45
connectors located on the
back of each server node.
Four auto-sensing
100/1000/10000 Base-T
Ethernet ports with RJ-45
connectors located on the
back of each server node.
Note - Optionally, you
can purchase the Sun Dual
10GbE SFP+ PCIe 2.0
Low Profile Adapter as a
replacement for the standard
InfiniBand adapter if an
Ethernet fiber connection
