Oracle Database Appliance X6-2S/X6-2M/X6-2L Status Indicators
16 Oracle Database Appliance Service Manual • June 2017
Callout Indicator/LED: Color State Meaning
■ Fast blink – This LED blinks to help locate the system. Operators
can turn this indicator on and off remotely using Oracle ILOM.
■ Pressing this button toggles the fast blink on or off.
2 Service Required: amber ■ Off – Normal operation.
■ On – A fault is present in the server node.
Note - The lighting of this indicator is always accompanied by a
system console message that includes a recommended service action.
3 OK: green Indicates the operational state of the server node:
■ On – The server is powered on, and all host POST code
checkpoint tests are complete. The server is in one of the
following states: 1) the server host is booting the operating
system (OS), 2) the server host is running the OS.
■ Off – AC power is not present or the Oracle ILOM boot is not
complete.
■ Steady blink – Standby power is on, but the chassis power is off
and the Oracle ILOM SP is running.
■ Slow blink – Startup sequence has been initiated on the host.
This pattern should begin soon after you power on the server.
This status indicates either: (1) POST code checkpoint tests are
running on the server host system, or (2) the host is transitioning
from the powered-on state to the standby state on shutdown.
4 Power button Press to apply full power. Press again to turn main power off, but
leave standby power on the Oracle ILOM.
5 Service processor (SP): green ■ Off – The service processor (SP) is not running.
■ On – The SP is fully operational.
■ Slow blink – SP is booting.
6 Drive OK: green ■ Off – Power is off or the installed drive is not recognized by the
system.
■ On – The drive is engaged and is receiving power.
■ Random blink – There is disk activity. The indicator blinks on
and off to indicate activity.
7 Drive Service Required: amber ■ Off – The storage drive is operating normally.
■ On – The system has detected a fault with the storage drive.
8 Drive Ready-to-Remove: blue ■ Off – The storage drive has not been prepared for removal.
■ On – The storage drive can be removed safely during a hot-plug
operation.
9 Top fan: amber
Rear PS: amber
Over-temperature warning:
amber
Top fan:
■ Off – Indicates steady state; no service is required.
■ On – Indicates service required; service the failed fan module.
Rear PS:
■ Off – Indicates steady state; no service is required.
■ On – Indicates service required; service the failed power supply.
Over-temperature warning:
■ Off – Normal operation; no service is required.
To Next Page
