Oracle Database Appliance X6-2-HA Status Indicators
18 Oracle Database Appliance Service Manual • June 2017
Callout Indicator/LED: Color State Meaning
Top right activity indicator:
■ On – Link up.
■ Off – No link or link down.
■ Blinking – Packet activity.
5, 6 PS Service Required: amber
PS OK: green
PS Service Required:
■ Off – Normal operation.
■ On – The power supply (PS) has detected a PS fan failure, PS
over-temperature, PS over current, or PS over or under voltage.
PS OK:
■ Off – No AC power is present.
■ On – Normal operation. Input AC power and DC output voltage
are within specification.
■ Slow blink – Normal operation. Input power is within
specification. DC output voltage is not enabled.
7 System locate, service required
and OK: various
These operate in the same way as on the front panel.
8 NET 0-3 ports: green/amber 100/1000/10000 BASE-T Ethernet management interface.
Top left activity indicator:
■ On – No function.
■ Off – No activity.
■ Blinking – Packet activity.
Top right link indicator:
■ On – Amber for 1000Base-T link; green for 10GBBase-T link.
■ Off – 100BASE-T link.
■ Blinking – No function.
Oracle Database Appliance X6-2-HA Status Indicators
The following topics describe the Oracle Database Appliance X6-2-HA status indicators. They
include controls and indicators on the server nodes and storage shelf front panel, hard drives,
SSD drives, power supplies, and SAS I/O modules.
■
“Oracle Database Appliance X6-2-HA Server Node Status Indicators” on page 19
■
“Oracle Database Appliance X6-2-HA Storage Shelf Indicators” on page 22
