Install Boot Disk Backplane Cables
202 Oracle Database Appliance Service Manual • June 2017
This section describes installing the boot disk backplane cables in Oracle Database Appliance
Version 1.
1.
Reconnect the power cable and hard disk drive (HDD) cables.
a.
Reconnect the power cable and HDD cables to the boot disk backplane [2].
b.
Reconnect the power cable and HDD cables to the motherboard [1].
2.
Return the server node to operation.
a.
Install the server node top cover.
See “Installing the Server Node Top Cover” on page 207.
b.
Install the server node into the system.
See “Installing a Server Node Into the System Chassis” on page 208.
c.
Power on the server node.
See “Powering On Oracle Database Appliance Version 1” on page 210.
Servicing the Motherboard Assembly (FRU)
Note - Information in this appendix does NOT apply to Oracle Database Appliance X3-
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
Each Oracle Database Appliance Version 1 server node has a motherboard assembly. The
service strategy for the motherboard is to remove the replaceable components from the server
node and then return the server node with the motherboard in place to Oracle for repair or
replacement.
The motherboard assembly is a FRU and can only be replaced by an Oracle-qualified service
technician.
Caution - Equipment damage. These procedures require that you handle components that are
sensitive to static discharge. This sensitivity can cause the component to fail. To avoid damage,
ensure that you follow antistatic practices as described in “Performing Electrostatic Discharge
and Antistatic Prevention Measures” on page 112.
