Servicing Oracle Database Appliance X6-2 Series FRUs
82 Oracle Database Appliance Service Manual • June 2017
Oracle Database Appliance X6-2S/
X6-2M
Oracle Database Appliance X6-2L Oracle Database Appliance X6-2-HA
Note - For this product, the NVMe
Switch Card is located in Slot 2.
Note - For this product, the NVMe
Switch Cards are located in Slots 2,
5 and 6.
Servicing the internal host bus
adapter (HBA) (FRU)
“Servicing the Internal SAS
Host Bus Adapter (HBA)
(FRU)” on page 83
Servicing the internal host bus
adapter (HBA) (FRU)
Servicing the Disk Backplane (FRU) Servicing the Front Storage Drive
Backplane (FRU)
Removing the Rear Storage Drive
Backplane (FRU)
Installing the Rear Storage Drive
Backplane (FRU)
Note - For this product, there is
a single SAS cable that connects
directly from the PCIe HBA in slot
3 to the rear storage drive backplane.
It does not route through the chassis
mid-wall.
Servicing the Disk Backplane (FRU)
Servicing the DVD Drive (FRU) This product does not include a slot
for a DVD drive.
Servicing the DVD Drive (FRU)
Servicing the Front Indicator Module
(FRU)
Servicing the Front LED/USB
Indicator Modules (FRU)
Servicing the Front Indicator Module
(FRU)
Servicing the Motherboard (FRU) Servicing the Motherboard (FRU) Servicing the Motherboard (FRU)
Servicing the SAS Cables (FRU) “Replace the Internal SAS HBA
Cables” on page 88
Note - For this product, there is
a single SAS cable that connects
directly from the PCIe HBA in slot
3 to the rear storage drive backplane.
It does not route through the chassis
mid-wall.
Servicing the SAS Cables (FRU)
Servicing the NVMe Cables (FRU)
Note - The NVMe Switch Card
is located in PCIe slot 2 for this
product.
Servicing the NVMe Cables (FRU)
Note - The NVMe Switch Cards are
located in PCIe slots 2, 5 and 6 for
this product.
This product does not have NVMe
devices.
Servicing the Power, FIM, Disk
Backplane Data, and DVD Cables
(FRU)
For this product, cabling for Front
Indicator Modules and the disk
backplanes are included as part of
the FRU servicing procedure for
those components listed earlier in
this table.
Servicing the Power, FIM, Disk
Backplane Data, and DVD Cables
(FRU)
“Component Fault
Management” on page 91
“Component Fault
Management” on page 91
“Component Fault
Management” on page 91
