Replace the Internal SAS HBA Card
Chapter5 • Servicing FRUs 87
Note - PCIe slot 3 is the reserved slot for the Oracle Storage 12 Gb/s SAS PCIe RAID HBA
card.
12.
Install the super capacitor in the chassis.
a.
Lower the air baffle to the installed position.
b.
Align the recloseable fastener on the super capacitor with the recloseable
fastener on the air baffle and press down [1].
