Server Overview
Steps Description Links
9. Connect the power cords to the server, configure the Oracle
ILOM on the SP, power on the server for the first time, and set
up the operating system.
“Powering On the Server for the First Time” on page 57
Related Information
■
SPARC S7-2 Server Product Notes
■
SPARC S7-2 Server Safety and Compliance Guide
■
Servers Administration
■
Server Service
Server Overview
This topic provides a high-level introduction to the main components and capabilities of the
server.
Component Description
Chassis Rack-mountable server.
CPU One or two processors are supported: 8-core, 4.267GHz, 130W each, installed on the
motherboard assembly.
Memory 16 DDR4 DIMM slots are supported:
■ Each processor module supports either 4 or 8 DIMMs for a total of 8 or 16 DIMMs in two
processor systems.
■ Mixing of memory types or sizes is not supported.
I/O expansion Three low profiles x8 PCIe Gen3 slots. All slots support x8 PCIe cards, two slots support x16
PCIe cards mechanically.
Storage devices For internal storage, the server provides:
■ Eight 2.5-inch drive bays accessible through the front panel, support SFF SAS/SATA
drives with 4 slots NVMe enabled.
■ Internal SAS HBA card.
■ Support for non-RAID LSISAS3008 HBA.
USB ports Two external USB 2.0 ports (front panel).
Ethernet ports Four 10GbE 100/1000/10000 Mbps, RJ-45-based ports on the rear panel.
Power supplies Two hot-swappable A266 1.2kW (N+1).
Cooling fans Four hot-swappable, redundant fans at chassis front (top-loading).
SP Oracle Integrated Lights Out Manager (Oracle ILOM) on motherboard.
Understanding the Server 11
