Page #16 background image
Electrical Specifications
“Handling Precautions” on page 22
“Installing the Server” on page 25
“Electrical Specifications” on page 16
“Environmental Specifications” on page 17
“Airflow Precautions” on page 18
Electrical Specifications
Description Value
Operating Input Range 100 to 120 VAC; 200 to 240 VAC; 50-60 Hz
Max Operating Input Current per cord at 100VAC 8.6 A
Max Operating Input Current per cord at 200VAC 4.1 A
Max operating input power at 100VAC 851 W
Max operating input power at 200VAC 819 W
Maximum heat dissipation 2904 BTU/hr
3064 KJ/hr
Maximum standby power 23.4 W
Maximum server configuration specification under nominal temperature and voltage conditions
(SPARC S7-2, Two 4.267GHz S7 Processors, 16 64GB DDR4 DIMMS, 4 SAS + 4 NVMe-SFF drives , 1 Internal HBA card, 3 PCIe cards)
Idle AC input power 412 W
Peak AC input power running MGRID 749 W
Minimum server configuration specification under nominal temperature and voltage conditions
(SPARC S7-2-1S, One 4.267GHz S7 Processors, 4 16GB DDR4 DIMMS, 0 drives, 1 Internal HBA card, 0 PCIe cards)
Idle AC input power 190 W
Peak AC input power running MGRID 352 W
For information on power specifications, use the power calculator at:
http://www.oracle.com/us/products/servers-storage/sun-power-calculators
Related Information
“Powering On the Server for the First Time” on page 57
16 SPARC S7-2 Server Installation Guide • July 2016
