Stabilize the Rack
No. Description
1 Slide-rails
2 Mounting brackets
3 Four M4 x 5 fine-pitch mounting bracket securing screws (optional)
4 Installation card
Related Information
■
“Rack Compatibility” on page 26
Stabilize the Rack
Caution - To reduce the risk of personal injury, stabilize the rack by extending all anti-tilt
devices before installing the server.
Refer to the rack documentation for detailed instructions for the following steps.
1.
Read the rack cautions and stabilize the rack.
See “Rack Cautions” on page 27.
2.
Open and remove the front and rear doors from the rack.
3.
To prevent the rack cabinet from tipping during the installation, stabilize the
cabinet using all antitilt mechanisms provided.
Installing the Server 29
