Mark the Rackmount Location
The bottom edge of the card corresponds to the bottom edge of the server. Measure up from the
bottom of the installation card.
3.
Mark the mounting holes for the front slide-rails.
4.
Mark the mounting holes for the rear slide-rails.
Related Information
■
“Rack Compatibility” on page 26
■
“Install Mounting Brackets Onto the Server” on page 30
■
“Attach Tool-less Slide-Rail Assemblies” on page 34
32 SPARC S7-2 Server Installation Guide • July 2016
