8
Installing an Oracle ZFS Storage ZS4-4 or
Oracle ZFS Storage ZS3-4 Controller
This section contains installation procedures for an Oracle ZFS Storage ZS4-4 or Oracle ZFS
Storage ZS3-4 controller.
Before beginning installation, see Installation Prerequisites and Hardware Overviews.
Use the following procedures to install an Oracle ZFS Storage ZS4-4 or Oracle ZFS Storage
ZS3-4 controller:
• Installing the Slide Rails onto an Oracle ZFS Storage ZS4-4 or Oracle ZFS Storage
ZS3-4 Controller
• Installing the Slide Rails into the Rack for an Oracle ZFS Storage ZS4-4 or Oracle ZFS
Storage ZS3-4 Controller
• Installing an Oracle ZFS Storage ZS4-4 or Oracle ZFS Storage ZS3-4 Controller onto the
Rack Slide Rails
• Installing an Oracle ZFS Storage ZS4-4 or Oracle ZFS Storage ZS3-4 Cable
Management Arm
Installing the Slide Rails onto an Oracle ZFS Storage ZS4-4 or
Oracle ZFS Storage ZS3-4 Controller
Use the following procedure to install the slide rails onto an Oracle ZFS Storage ZS4-4 or
Oracle ZFS Storage ZS3-4 controller.
Note:
The slide rails can be used with either 9.5-mm square or M6 round mounting hole
racks.
1. Position a mounting bracket against the chassis so that the slide-rail lock is at the front of
the chassis, and the five keyhole openings on the mounting bracket are aligned with the
five locating pins on the side of the chassis.
Note:
The mounting brackets are identical and can be installed on either side of the
chassis.
8-1
