Oracle ZFS Storage DE3-24P User Manual

1 Serial 1 2 Ethernet 3 Serial 0
4 Serial Link Status LED 5 Ethernet Link Status LED 6 Ethernet Activity LED
The following diagram illustrates the cluster serial and Ethernet ports for Oracle ZFS Storage
ZS3-2 controllers.
1
Serial Link Status LED 2 Ethernet 3 Serial 0
4 Serial 1 5 Ethernet Link Status LED 6 Ethernet Activity LED
Connecting Disk Shelf Cables
Use the following procedure to connect the cables between storage controller(s) and disk
shelves.
Chapter 11
Connecting Disk Shelf Cables
11-7

Oracle ZFS Storage DE3-24P Specifications

General

Model	Oracle ZFS Storage DE3-24P
Drive Bays	24
Drive Size	2.5-inch
Connectivity	SAS-3
Operating System	Oracle Solaris with ZFS
Supported Drive Types	SSD, HDD
Controller	Dual-controller
Networking	10 GbE, 40 GbE
Power Supply	Dual redundant
RAID Support	RAID 0, 1, 5, 6, 10
