Overview of the Oracle ZFS Storage ZS7-2 Controller
This section provides an overview of the Oracle ZFS Storage ZS7-2 controller. For installation
instructions, refer to Installing an Oracle ZFS Storage ZS7-2 Controller. For service
instructions, refer to Servicing the ZS7-2 Controller in Oracle ZFS Storage Appliance
Customer Service Manual, Release OS8.8.x.
Refer to https://oracle.com/zfsstorage for the most recent component specification.
Oracle ZFS Storage ZS7-2 Physical Specifications
The Oracle ZFS Storage ZS7-2 controller chassis dimensions are as follows:
Dimension Measurement Dimension Measurement
Height 3.42 in./8.69 cm Depth 29.9 in./75.9 cm
Width 17.5 in./44.5 cm Weight (Maximum) 63 lb./28.6 kg
Oracle ZFS Storage ZS7-2 Electrical Specifications
The Oracle ZFS Storage ZS7-2 controller has two hot-swappable rear accessible power
supplies with N+N redundancy. To understand the overall power consumption, see Oracle's
online power calculator at http://www.oracle.com/goto/powercalculators .
Parameter AC Power Supplies
Nominal input frequencies 50/60 Hz
Operating input voltage range 100-240 VAC
Rated input current 10 A @ 100 to 127 VAC and 7 A @ 200 to 240
VAC
Maximum power consumption of controller Refer to the Power Calculator (https://
www.oracle.com/goto/powercalculators) and see
Oracle Server X7-2L for Watt calculations
Maximum heat output of controller Refer to the Power Calculator (https://
www.oracle.com/goto/powercalculators) and see
Oracle Server X7-2L for BTU/hr calculations
Oracle ZFS Storage ZS7-2 Acoustic Noise Emissions
The workplace-dependent noise level of this product is 8.1 Bels A-weighted Operating, and
5.8 Bels A-weighted Idling (measured Sound Power).
Oracle ZFS Storage ZS7-2 Configuration Options
The Oracle ZFS Storage ZS7-2 high-end model incorporates one or two controllers and one
to forty-eight disk shelves. Each controller has 11 PCle Gen3 slots in the rear, and 12 3.5"
disk slots in the front, two of which are occupied by system disks. Read cache devices are
installed in disk shelves; therefore, the remaining ten front disk slots have permanent filler
panels. The following table describes the configuration options.
Chapter 2
Overview of the Oracle ZFS Storage ZS7-2 Controller
2-31
