Disk Shelf Components
The following sections describe each disk shelf's components:
Oracle Storage Drive Enclosure DE3-24P Components
• Oracle Storage Drive Enclosure DE3-24P Base Chassis
• Filler Panel, Oracle Storage Drive Enclosure DE3-24P
• Up to 24 2.5" SAS-3 HDDs, SSDs
Oracle Storage Drive Enclosure DE3-24C Components
• Oracle Storage Drive Enclosure DE3-24C Base Chassis
• Filler Panel, Oracle Storage Drive Enclosure DE3-24C
• Up to 24 3.5" SAS-3 HDDs, SSDs
Oracle Storage Drive Enclosure DE2-24P Components
• Oracle Storage Drive Enclosure DE2-24P Base Chassis
• Filler Panel, Oracle Storage Drive Enclosure DE2-24P
• Up to 24 2.5" SAS-2 or SAS-3 HDDs, SSDs
Oracle Storage Drive Enclosure DE2-24C Components
• Oracle Storage Drive Enclosure DE2-24C Base Chassis
• Filler Panel, Oracle Storage Drive Enclosure DE2-24C
• Up to 24 3.5" SAS-2 or SAS-3 HDDs, SSDs
Sun Disk Shelf (DS2) Components
• Sun Disk Shelf (DS2) 24x3.5" SAS-2
• Sun Disk Shelf (DS2) 24x3.5", LOGFiller
• Disk Shelf Rail Kit
• Up to 24 3.5" SAS-2 HDDs, SSDs
Overview of the Oracle ZFS Storage ZS9-2 Controller
This section provides an overview of the Oracle ZFS Storage ZS9-2 controller. For installation
instructions, refer to Installing an Oracle ZFS Storage ZS9-2 Controller. For service
instructions, refer to Servicing the ZS9-2 Controller in Oracle ZFS Storage Appliance
Customer Service Manual, Release OS8.8.x.
Refer to https://oracle.com/zfsstorage for the most recent component specification.
Oracle ZFS Storage ZS9-2 Physical Specifications
The Oracle ZFS Storage ZS9-2 controller chassis dimensions are as follows:
Chapter 2
Overview of the Oracle ZFS Storage ZS9-2 Controller
2-27

Oracle ZFS Storage DE3-24P Specifications

General

Brand	Oracle
Model	ZFS Storage DE3-24P
Category	Storage device
Language	English
