Oracle ZFS Storage DE3-24P User Manual

1 Locate indicator 2 Service required indicator 3 OK indicator
4 Power supply fault indicator 5 SAS I/O Module fault indicator 6 Ready-to-remove indicator
7 Drive service required indicator 8 Power/Activity indicator
Oracle Storage Drive Enclosure DE3-24C Rear Panel
1 Power supply filler panel, slot 4
2 I/O Module 1 3 I/O Module filler panel
4 Power supply with fan module
2
5 Power supply filler panel, slot 2 6 I/O Module filler panel
7 I/O Module 0 8 Power supply with fan module
1
Note:
It is especially important that power supplies and their filler panels are in the correct
slots.
Oracle Storage Drive Enclosure DE3 I/O Module Indicators
Chapter 2
Overview of Disk Shelves
2-19
