IGS-3032GC User’s Manual
36
Label Description
Enable
Enabling the Open-Ring function
Vender
Choosing the venders that you want to join to their ring
1
st
Ring Port
Choosing the primary port which connect to the ring
2
nd
Ring Port
Choosing the backup port which connect to the ring
The application of Open-Ring is shown as below.
Open-Ring connection
5.1.5.3 O-RSTP
O-RSTP is proprietary redundant ring technology invented by O-Ring. Different from
standard STP/RSTP, the recovery time of O-RSTP is less than 20ms and support more nodes
of connection in a ring topology.
