IGS-3032GC User’s Manual
6
Hardware Installation
2.1 Installation Switch on DIN-Rail
Each switch has a DIN-Rail kit on rear panel. The DIN-Rail kit helps switch to fix on the
DIN-Rail. It is easy to install the switch on the DIN-Rail:
2.1.1 Mount IGS-3032GC on DIN-Rail
Step 1: Slant the switch and mount the metal spring to DIN-Rail.
Metal S
p
rin
g
